Aluminum Panel FAQ

Factory-direct price for 3mm PVDF aluminum panel ranges from $25–$48/m² depending on alloy grade, coating system, and order volume. 2.5mm panels start around $22/m², while 4mm custom-shaped panels can reach $55/m². Custom colors, perforation, and small-batch orders incur additional cost. Contact us for a detailed project-specific quote.

For exterior curtain wall applications, 2.5mm–3.0mm is standard for flat panels (AA3003-H24 alloy). For large or perforated panels, 3.0mm–4.0mm is recommended to prevent oil-canning. Minimum 2.0mm for interior applications. Per GB/T 23443 and common GCC specifications, 3.0mm is the most widely specified thickness for exterior use.

3mm AA3003-H24 solid aluminum panel weighs approximately 8.1 kg/m² without coating. With PVDF 3-coat finish, add ~0.3 kg/m² for a total of ~8.4 kg/m². For comparison, 25mm honeycomb panels of equivalent rigidity weigh only 5.5–7.0 kg/m² — about 30% lighter.

PVDF (fluorocarbon) is superior for exterior use. PVDF lasts 15–25 years vs polyester powder 5–8 years in harsh climates. PVDF carbon-fluorine bonds (485 kJ/mol) resist UV/chemical attack far better than polyester C-C bonds (347 kJ/mol). Powder coating is 30–40% cheaper. Industry practice: use powder for interiors, PVDF for exteriors.

Solid aluminum panels (2.5mm+) achieve A2-s1,d0 per EN 13501-1 and Class A per ASTM E84 — the highest fire ratings for cladding materials. This is critical for GCC high-rise projects where PE-core ACP (aluminum composite panel) is banned. Aluminum honeycomb panels also achieve A2-s1,d0 rating.

Standard installation uses the dry-hang method: (1) Install steel/aluminum sub-frame and keel system at 600mm intervals, (2) Attach angle-code brackets to keel, (3) Hang panels with screws/rivets through pre-drilled holes, (4) Apply weatherproof sealant between joints, (5) Install flashing and edge trims. We provide CAD shop drawings and installation guidance with every order.

Five key criteria: (1) Verify ISO 9001:2015 certification and request audit reports, (2) Ask for QUV test reports (≥3000h for PVDF), (3) Request reference projects in your target market, (4) Confirm factory-direct pricing to avoid trading company markups of 20–40%, (5) Test with a sample order before committing to large volumes.

Solid aluminum panel is a single-layer aluminum sheet (2.0–4.0mm), achieving A2-s1,d0 fire rating. ACP has two thin aluminum skins (0.5mm) bonded to a PE or mineral core. PE-core ACP is banned in UAE high-rise buildings due to fire risk. Solid aluminum panels are specified where fire compliance is critical. ACP is cheaper but offers lower fire performance.

Standard products: 50 m² minimum. Custom colors: 200 m² minimum. Sample panels available from 1 piece for project qualification. We welcome small-batch orders for trial projects and pre-qualification purposes.

7–30 days depending on complexity (flat < perforated < curved), quantity, coating system (powder faster than PVDF), and production schedule. Rush orders available with 5–7 day turnaround for standard specifications. PVDF 3-coat curing alone requires 24–48 hours.

Honeycomb aluminum panel has an aviation-grade aluminum honeycomb core sandwiched between two aluminum skins (total thickness 10–50mm). It is 70% lighter than solid aluminum of equivalent rigidity, offers superior flatness for large spans up to 2000×6000mm, and achieves A2-s1,d0 fire rating. Use it for: large ceiling spans, column covers, airport terminals, and projects where weight reduction is critical.

Three primary alloys: AA1100 (99% purity, excellent corrosion resistance, for interior/non-structural), AA3003-H24 (manganese alloy, good formability, the industry standard for curtain walls), AA5052 (magnesium alloy, higher strength, for marine/coastal applications). AA3003-H24 is the most commonly specified alloy for exterior facades.

Yes, PVDF-coated aluminum panels are specifically engineered for extreme desert climates. Our panels maintain color stability at 50°C+ with QUV 3000h test passing (ΔE ≤ 2.0). PVDF carbon-fluorine bonds resist the intense UV radiation that degrades polyester coatings within 24 months. We have supplied multiple projects in the UAE, Saudi Arabia, and Qatar.

Four main options: (1) PVDF/Fluorocarbon — 70% resin, ≥25μm DFT, 15–25 year warranty for exterior use. (2) Polyester powder coating — 60–80μm, economical for interior applications. (3) Anodizing — natural silver/bronze finish, 15–20 year durability. (4) Wood grain heat transfer — 98% visual realism with A2 fire rating, 40+ species available.

Standard maximum sheet size: 2000mm × 6000mm for flat panels. Common project sizes: 600mm–1200mm wide × 1200mm–3000mm tall. Custom sizes available within the maximum sheet dimensions. Larger panels reduce joint count but may require thicker gauge for flatness.
