Robotics & Automation Aluminum

E Expert Experience

For a 6-axis industrial robot arm manufacturer in Japan, we machined the base mounting plate to a flatness of 0.02mm and a surface finish of Ra 0.8μm—critical for maintaining the robot's positional accuracy over millions of cycles. A single micron of flatness error translates to 0.5mm positional error at the robot's end effector. We also developed a lightweight honeycomb arm cover for a collaborative robot (cobot) application that reduced weight by 40% compared to the previous steel design while maintaining ISO 10218-2 safety margins for human-robot collaboration. Our ISO 9001:2015 certified process includes 100% CMM inspection on critical dimensions before shipment.

T Technical Specifications

**Core Specifications:**
• Materials: AA6061-T6 / AA7075-T651 (high strength) / AA5083-H111 (welding grade)
• Dimensional tolerance: ±0.02mm (CNC machined) / ±0.1mm (fabricated)
• Flatness/Parallelism: ≤0.02mm / 1000mm (CNC machined critical surfaces)
• Surface finish: Ra 0.4 – Ra 3.2μm (machined) / Ra 6.3μm (sheet metal)
• Process: CNC milling & turning / Sheet metal forming / Welding (MIG/TIG) / Assembly
• Anodizing: Type II (standard) / Type III hard anodize (wear-resistant, 25-50μm)
• Fasteners: Dowel pins (Class 2 tolerance) / Helicoil inserts (for repeated assembly)
• Quality: 100% CMM inspection for critical dimensions / Dimensional report with each shipment

Applications
